Applicable Material
Metal and Non Metal
Cooling System
Air Cooling
Technical Class
Continuous Wave Laser
Laser Wavelength
Fiber Laser
Laser Classification
Fibre Laser
Type
Optical Fiber Laser Marking Machine
Marking Method
Scanning Marking
Power
20/30/50/60/100/120/200/300W
Marking Area-1
110X 110mm(4.3X43in)
Marking Area-2
150X 150mm(5.9X59in)
Marking Area-3
175X 175mm (6.9X6.9in)
Maximum Material Thickness-1
300mm(11.8in)(at)110X 110mm
Maximum Material Thickness-2
250mm(9 Bin)(at)150 X 150mm
Maximum Material Thickness-3
206mm(8.1in)(at)175X 175mm
Laser Type
Raycus/Ipg/Jpt Optional
Key Selling Points
Low Maintenance Cost
Applicable Industries
Hotels, Garment Shops, Building Material Shops, Ma
Machine Type
CNC Laser Marker
Machinery Type
Laser Marking Machine
Certification
CE, ISO 9001, FCC, Reach, UL, TUV, SGS, CB, EAC, a
Transport Package
Wooden Box
Specification
550X450X650mm
Origin
Jinan, Shandong, China
Production Capacity
85000 Sets Per Year
Packaging & Delivery
Package Size
78.00cm * 48.00cm * 60.00cm
Package Gross Weight
45.000kg
Product Description
|
Power
|
20/30/50/60/100/120/200/300W
|
|
Marking Area
|
110X 110mm(4.3X4.3in)
|
|
150X 150mm(5.9X5.9in)
|
|
175X 175mm (6.9×6.9in)
|
|
200x200mm (7.87×7.87in)
|
|
220x220mm (8.66×8.66in)
|
|
Above free of charge
|
|
Laser Type
|
Fiber (CO2/UV available)
|
|
Wavelength
|
1064nm
|
|
Repetitive Frequency
|
20-80KHZ
|
|
Fundamental Gaussian Beam
|
<2
|
|
Carving Line Speed
|
≤10000mm/s
|
|
Minimum Line Width
|
0.01mm
|
|
Minimum Character
|
0.15mm
|
|
Repeatability
|
±0.002
|
|
Power Supply
|
220V/50Hz
|
|
Power Consumption
|
500W
|
|
Engraving Depth
|
≤3mm
|
|
Engraving Speed
|
≤7000mm/s
|
|
Graphic Format Supported
|
BMP, JPG, PNG, DXF
|
Material: High-grade aluminum alloy with anti-corrosion coating for long-term durability.
Surface Precision: Ultra-flat design (±0.1mm tolerance) guarantees uniform marking quality across materials.
Heat Resistance: Withstands temperatures up to 300°C, ideal for high-power laser applications.
Advantages:
Enhances marking accuracy with vibration-dampening properties. Lightweight yet rigid structure for easy repositioning. Low maintenance with scratch-resistant surface.
Customization: Tailored labeling, color coding, and functional layouts (emergency stop, start/pause, power).
Durability: Industrial-grade materials (IP65 rating) resistant to dust, moisture, and mechanical wear.
Advantages:
Streamlines production with programmable shortcuts.
Enhances safety with emergency stop functionality.
Brandable interface to align with corporate identity.
Scan Speed: Up to 7,000 mm/s with ±0.001° repeatability.
Laser Compatibility: Works with fiber, CO2, and UV lasers.
Dynamic Focus: Integrated f-theta lens for consistent spot size across large working areas.
Durability: High-torque galvanometer motors rated for 100 million cycles.
Advantages:
Reduces cycle time by 40% compared to standard scanners.
Maintains sharpness on curved or uneven surfaces.
Supports ultra-fine details (line widths down to 20μm).
Super-Large Range Adjustable Lift Column (Upgradable to Electric)
Universal Interfaces (Customizable for 99%+ Buyer Needs)
Mass Production Availability (FCL Container Orders)
Advantages:
Reduces setup time by 60% with one-touch height presets.
Future-proof design allows easy integration with robotics or conveyor systems.
Applications:
Large automotive components, aerospace parts, and heavy machinery serialization.
Advantages:
Eliminates adapter costs with plug-and-play compatibility.
Scalable for Industry 4.0 smart factory integration.
Waterproof connectors (IP67-rated) ensure reliability in dusty/humid conditions.
Production Line Shots:
Real-time marking operations on stainless steel, ceramics, and engineered plastics
3rd party inspection avaialble based on buyers’s demand.
Unmatched Precision and Power
The MOPA Fiber Laser Marking Machine is engineered to deliver exceptional marking performance, whether you need fine details or high-speed processing. Available in a range of power options from 20W to 300W, this machine caters to diverse applications, ensuring high-quality results for a wide variety of materials. Its cutting-edge MOPA (Master Oscillator Power Amplifier) technology enables you to achieve superior versatility, from marking metals and plastics to colored markings on stainless steel.
Versatile and Reliable for Various Industries
Designed to meet the demands of industries like electronics, automotive, medical devices, and consumer goods, the MOPA Fiber Laser Marking Machine offers unparalleled reliability and adaptability. Its user-friendly interface and robust design simplify operations, whether you’re etching intricate patterns or batch marking high volumes. The flexibility of adjustable pulse widths and power levels allows compatibility with different materials, making this machine a trusted partner for manufacturers and creators alike.
Why Choose the MOPA Fiber Laser Marking Machine?
This state-of-the-art marking machine doesn’t just prioritize precision—it excels in energy efficiency and durability. Features like low maintenance requirements, high-speed performance, and exceptional consistency make it a cost-effective solution for businesses of all sizes. Whether you’re seeking detailed engravings or fast, clean marks, the MOPA Fiber Laser Marking Machine ensures optimal results, helping your products stand out in competitive markets.
